Fastening Capacities
: Standard Bolt: M10 - M24 (3/8 - 1")
: High Strength Bolt (Grade 10.9): M10 - M16 (3/8 - 5/8")
Square Drive
: 12.7 mm (1/2")
No Load Speed (RPM)
: Max / Hard / Mid / Soft: 0-2,300 / 1,900 / 1,200 / 600
Impacts Per Minute (IPM)
: Max / Hard / Mid / Soft: 0 - 2,900 / 2,700 / 1,900 / 1,200
Nut-Busting Torque
: 1,100 N·m (810 ft·lbs.)
Max Fastening Torque
: 760 N·m (560 ft·lbs.)
Vibration Level
: 19.7 m/s²
Sound Pressure Level
: 97 dB(A)
Sound Power Level
: 108 dB(A)
Dimensions (L x W x H)
: 170 x 86 x 312 mm (6-11/16 x 3-3/8 x 12-1/4")
Net weight
: 2.7 - 3.3 kg (6.0 - 7.3 lbs.)
