Fastening Capacities
: Standard Bolt: M10 - M20 (3/8" - 3/4")
: High Strength Bolt: M10 - M16 (3/8" - 5/8")
Square Drive
: 12.7 mm (1/2")
No Load Speed (RPM)
: Max / Hard / Mid / Soft: 0 - 3,200 / 2,600 / 1,800 / 1,000
Impacts Per Minute (IPM)
: Max / Hard / Mid / Soft: 0 - 4,000 / 3,400 / 2,600 / 1,800
Max Fastening Torque
: 350 N·m (260 ft.lbs.)
Vibration Level
: 16.5 m/s²
Sound Pressure Level
: 99 dB(A)
Sound Power Level :
: 110 dB(A)
Dimensions(L x W x H)
: 311x79x117 mm (12-1/4"x3-1/8"x4-5/8")
Net weight
: 1.4 - 1.7* kg (3.1 - 3.7* lbs.)
