Blade Diameter
: 235 mm (9-1/4")
Max Cutting Capacity
: 90°: 85 mm (3-3/8")/45°: 61 mm (2-3/8")
: 60°: 44 mm (1-3/4")
No Load Speed (RPM)
: 4,500
Vibration Level
: Cutting Wood: 2.5 m/s² or less
: Cutting Metal: 2.5 m/s² or less
Sound Pressure Level
: 93 dB(A)
Sound Power Level
: 104 dB(A)
Dimensions (L x W x H)
: 413x196x316 mm(16-1/4"x7-3/4"x12-1/2")
Net weight
: 5.3 - 6.0 kg (11.7 - 13.2 lbs.)
