1. Maximum fastening torque of 180Nm for heavy duty applications

2. 4 stage speed selection & 4 Assist mode variations for optimised speed control

3. Compact design at 115mm in length for comfortable use in tight spaces

4. Quick switch button for single handed mode selection

5. Enhanced bit holder provides reduced bit wobble

Where to buy

Capacity	Machine Screw: M4 - M8 (5/32 - 5/16")
	Standard Bolt: M5 - M16 (3/16 - 5/8")
	High Strength Bolt: M5 - M14 (3/16 - 9/16")
Hex Shank	6.35 mm (1/4")
No Load Speed (RPM)	Max / Hard / Mid / Soft / Wood / Bolt / T (1) / T (2) mode:
	0 - 3,600 / 3,200 / 2,100 / 1,100 / 1,800 / 3,600 / 2,900 / 3,600
Impacts Per Minute (IPM)	Max / Hard / Mid / Soft / Wood / Bolt / T (2) mode:
	0 - 3,800 / 3,600 / 2,600 / 1,100 / 3,800 / 3,800 / 2,600
Max Fastening Torque	180 N·m (1,590 in.lbs.)
Fastening Torque	Hard / Mid / Soft: 170 / 50 / 20 N·m (1,510 / 440 / 180 in.lbs.)
Vibration Level	: 13.5 m/s²
Sound Pressure Level	97 dB(A)
Sound Power Level	108 dB(A)
Dimensions (L x W x H)	: 114 x 81 x 236 mm (4-1/2 x 3-3/16 x 9-1/4")
Net weight	1.2 - 1.5 kg (2.6 - 3.3 lbs.)
