Products

Capacity

Machine screw: M4 - M8 (5/32 - 5/16")

Standard bolt: M5 - M16 (3/16 - 5/8")

High strength bolt: M5 - M14 (3/16 - 9/16")

Steel: 22 mm (7/8")

Coarse thread (in length): 22 - 125 mm (7/8 - 4-7/8")

No Load Speed (RPM)

Max / Hard / Med. / Soft / T mode:

: 0 - 3,700 / 0 - 3,200 / 0 - 2,100 / 0 - 1,100 / 0 - 2,400

Impacts per minute (IPM)

Max / Hard / Med. / Soft: 0 - 4,100 / 0 - 3,600 / 0 - 2,600 / 0 - 1,400

Fastening torque

Hard / Med. / Soft: 170 / 50 / 20 N·m (1,510 / 440 / 180 in.lbs.)

Max fastening torque

: 210 N·m (1,860 in.lbs.)

Vibration Level

: 11.9 m/s²

Sound Pressure Level

: 95 dB(A)

Sound Power Level

: 106 dB(A)

Dimensions (L x W x H)

: 121 x 86 x 252 mm (4-3/4 x 3-3/8 x 9-7/8")

Net weight

: 1.7 - 2.9 kg (3.7 - 6.4 lbs.)
