Capacity
: Steel / Wood (Auger Bit / Self-Feed Bit / Hole
Saw) / Masonry:
13 / 36 / 35 / 51 / 13 mm(1/2 / 1-7/16 / 1-3/8 / 2 / 1/2")
Chuck Capacity
: 1.5 - 13 mm (1/16 - 1/2")
Impacts Per Minute (IPM)
: High / Low: 0 - 25,500 / 0 - 7,500
No Load Speed (RPM)
: High / Low: 0 - 1,700 / 0 - 500
Max Fastening Torque
: Hard / Soft: 40 / 25 N·m (350 / 220 in.lbs.)
Max Lock Torque
: 40 N·m (350 in.lbs.)
Vibration Level
: Impact Drilling into Concrete: 10.5 m/s²
Drilling into Metal: 2.5 m/s² or less
Sound Pressure Level
: 83 dB(A)
Sound Power Level
: 94 dB(A)
Dimensions (L x W x H)
: 164 x 81 x 248 mm (6-1/2 x 3-3/16 x 9-3/4")
Net weight
: 1.4 - 1.7 kg (3.1 - 3.7 lbs.)
